ốNG TRÍCH MẪU TubeTrace with BSX 3 (Electrically Heated Tubing Bundles)
ốNG TRÍCH MẪU, TubeTrace, with “cut-to-length” BSX 3 self-regulating heat tracing, is designed to provide freeze protection or temperature maintenance for tubing where no “steam out” of the tubing is possible. BSX withstands temperature exposures of 85°C (185°F). Self-regulating BSX heat tracing • Varies in response to the surrounding conditions along the entire length of a circuit. • Lower risk of overheating the tube or product. • Installed cost is lower because “cut-to-length” BSX makes end connections easy with minimal waste
FEATURES
- Freeze protection
- Low process temperature maintenance
- No steam clean
- Certified for use in ordinary (nonclassified) areas and in potentially explosive atmospheres
APPLICATION
TubeTrace, with “cut-to-length” BSX self-regulating
heat tracing, is designed to provide freeze protection or
temperature maintenance from 40°F (5°C) to 150°F (65°C)
for tubing where no “steam out” of the tubing is possible.
BSX withstands temperature exposures of 185°F (85°C).
Self-regulating BSX heat tracing:
• Varies in response to the surrounding conditions along
the entire length of a circuit.
• Lower risk of overheating the tube or product.
• Installed cost is lower because “cut-to-length” BSX
makes end connections easy with minimal waste.
• BSX is approved for use in ordinary (non-classified)
areas and hazardous (classified) areas
CONSTRUCTION
1 Process tube(s)
2 BSX self-regulating electrical heat tracing
3 Heat reflective tape
4 Non-hygroscopic glass fiber insulation
5 Polymer outer jacket (ATP or TPU available)
PRODUCT FEATURES
• Self-regulating
• “Cut-to-length”
• Hazardous area approvals
